7251F12 IEPE Accelerometer
100 mV/g, ±50 g, TEDS, -67°F to +257°F, isolated, thru-hole mount, side connector, 10.5 grams, IEEE P1451.4 TEDS v0.9
Features
- Thru-hole bolt mount IEPE accelerometer
- IEEE P1451.4 TEDS v0.9
- 360° cable orientation
- Hermetically sealed
- Ground isolated when installed with isolated mounting screw
7251F12
Data sheet
- Output type
- Voltage (IEPE)
- Max Measurement Range
- 50 g pk | 491 m/sec2 pk
- Number of Axis
- 1
- Weight
- 0.370 oz | 10.5 gm
- Sensitivity
- 100 mV/g | 10.2 mV/(m/sec2)
- Max Frequency (±5%)
- 10000 Hz
- Replacement (-R)
- No
